22KW Electric Vehicle Charger RFID Wall Mounted Fast Mini Wallbox AC EV Charging Station
22KW Electric Vehicle Charger RFID Wall Mounted Fast Mini Wallbox AC EV Charging Station
7kw 11kw 22kw mini Wallbox
type 2 iec 62196 ev charger evse wallbox
IEC 62196-2 (Type 2/Mennekes) plug
Additional information
| Model Number | FE-AM3-32mini |
|---|
|
Wallbox Product parameters
|
||||
|
Product Name
|
22KW Electric Vehicle Charger RFID Wall Mounted Fast Mini Wallbox AC EV Charging Station
|
|||
|
standrd
|
IEC standard
|
|||
|
certificates
|
CE,FCC
|
|||
|
Product Type
|
FE-AM3-16P3mini
|
FE-AM3-32mini
|
FE-AM3-32P3mini
|
|
|
AC Voltage Power Input
|
380v±10%
|
250V±10%
|
380v±10%
|
|
|
AC Power Output
|
11kw
|
7KW
|
22KW
|
|
|
Current Adjustable
|
8-16A
|
8-32A
|
8-32A
|
|
|
Rated Frequency
|
50/60HZ
|
|||
|
Charging Connector
|
IEC 62196-2 (Type 2/Mennekes) plug
|
|||
|
Internet Connection
|
Tuya App ,RFID Card
|
|||
|
Insulation resistance:
|
>1000MΩ（DC500V）
|
|||
|
Contact Resistance
|
0.5mΩMax
|
|||
|
Operating temperature:-
|
-30℃~+50℃
|
|||
|
Protection：Type B RCD
|
||||
|
Over Voltage Protection
|
yes
|
Under Voltage Protection
|
yes
|
|
|
Over Load Protection
|
yes
|
Short Circuit Protection
|
yes
|
|
|
Earth Leakage Protection
|
yes
|
Ground Protection
|
yes
|
|
|
Over-temp Protection
|
yes
|
Surge Protection
|
yes
|
|
|
Charging Cable Length
|
0.5m or Customize Length
|
|||
|
Application:
|
||||
|
Product dimensions
|
264.83*144.6*100mm
|
|||
|
IP Degree
|
IP65
|
|||
|
Control:
|
RFID Card
|
|||
|
Withstand voltage:
|
2000V
|
|||
|
Contact Resistance
|
0.5mΩMax
|
|||
|
Mechanical life:
|
no-load plug in / pull out > 10000times
|
|||
